Non-woven Fabrics & Melt-blown Fabrics Multi-section Slitting Machine, SHFQJ1800_Textile Machinery Parts_Industrial Supplies_Products

Top Selling

品牌：: SHOOT

Model: SHFQJ1800

Origin: Made In China

Label: Non-woven Fabric cut , meltblown fabric cut , pvc cut machine

Non-woven Fabrics And Melt-blown Fabrics Multi-section Slitting Machine
Feature
1. Cutting materials: non-woven fabrics, melt-blown fabrics, leather, PVC, PE industrial materials, chemical materials, etc.
2. Equipped with 10KG magnetic powder brake and electric eye correction function to control the unwinding and unwinding of the roll to ensure that the material is neat and tidy after slitting.
3. Rewinding and slitting adopt frequency conversion speed regulation to control the running speed of the whole machine.
Model	SHFQJ1800
Winding motor	4.0KW national standard pure copper motor
Cutter shaft motor	1.5KW national standard pure copper motor
Mother Roll diameter	1200mm
Mother roll width size	1800mm
Finish roll diameter	800mm
Unwinding error correction	<=0.5mm
Pneumatic shaft for winding and unwinding	3 inches (only for 74-78mm paper tube inner diameter, or customized according to customer requirements)
Min slitting width	20mm (Can simultaneously adjust other sizes)
Cutting accuracy	+/-0.1mm
Cutting speed	5-120m/min
Cutting thickness	15-300g/m2
Total power	5.5KW
Power supply	AC380V 50HZ
Weight	1000kg
Dimensions	2650x1200x1100mm

Contacts

Company Name: Yantai Shoot Woodworking Machine Co.,Ltd

Name:: Mr. Qujun

Telephone: +86-535-8949911

Address

Operational Address: No.113,Zhengfu Street Muping District, Yantai City ,Shandong ,China
