PNB-100 Nano Fish-removing Cleaning System

PNB-100 Nano Fish-removing cleaning system

Configuration: using intelligent central control system, and submersible micro and nano module, can be PLC control according to the requirements, with alarm system.

Main parameters: ozone micro-nano bubbles, mainly 5-8 cubic micro-nano water flow, five cleaning modes, with time control system

Use: placed in the sink, filled with water can start, 8 hours of high strength continuous use.

Parameter

Model number: PNB100

Host system size: 560 * 650 * 1400mm submersible size: 450 * 220 * 480mm

System composition: oxygen production module + ozone preparation module + anti-backwater function + PLC control system + diving micro-nano module, etc

Bubble technology: 100-300nm ozone occurrence amount: 100g / hr

Cooling: Water cooling

Power supply

:220V

Power: 3KW

Flow rate: 5-8m³ / H

Material: 304 stainless steel

Collocation: need power / origin, with nano bubble system working condition: can work for 8 hours for long time

Energy required: power supply, cooling water pipe

Consumables: none

 System configuration:
