two color automatic UV screen printer Spare Parts For Rotary Screen Printer

Two color automtic UV screen printer LC-SU215UV

Instructions

This screen printer specially design for circular shaped applications such as tubes,caps and injection molds bottles



This printer with servo optical fiber indexing system. It is possible to do multi-colors printing and overpint for some applications



This screen printing machine intergrates automatic feeding device, flame treatment and UV curing system and so on.



It combines mechanical driven with pneumatic driven, and LED display. The maximun printing capacity of the machine is 4200pcs per hour.



This system is equipped with various warning devices such as low pressure and overloading.The sensor can detect"no product, no printing".



The electrical components and control system adopt from Japan and Germany, ensure good printing quality.We provide screen printer and other machine design and construction services for special application.

Main part of this screen printing machine

1. MAIN MOTOR: SITI(Italy)
2. PLC:  Omron(Japan)
3. SENSOR: Optex(Japan)
4. TOUCH SCREEN: Proface(Japan)
5. Switch: Schneider(France)
6. CONTACTOR:Schneider(France)
7. RELAY: Idec(Japan)
8. INVERTER: Omron(Japan)
9. UV CURING (Primarc)Britain
10. Cylinder:Festo(Germany)

Parameter

Two color automtic UV screen printer LC-SU215UV
Max printing length	100*150mm
Object application dimension	12mm<D<35mm
	20mm<L<150mm
Power supply	AC380V 3Phase 50Hz 10KW
Air supply	6Bar
Max running speed	4200pcs/Hr
Machine dimension	L*W*H:2600*1700*1900mm
Machine weight	1400kg
