wide band Duplexer

NO.

Items

Parameters

RX

TX

1

Frequency Range

410MHz -415MHz

420MHz -425MHz

2

Insertion Loss

≤2.0dB

≤2.0dB

3

Pass Band Ripple

≤1.0dB

≤1.0dB

4

Attenuation Out of Band

≥85dB@ DC-400MHz

≥90dB@420-425MHz

≥85dB@425-3000MHz

≥85dB@ DC-410MHz

≥90dB@ 410-415MHz

≥85dB@435-3000MHz

5

Isolation

≥90dB

6

VSWR

≤1.35

7

Average Power

≥60W

8

RF Connection Mode

ANT:SMA/F,50Ω;

RX: SMA/F,50Ω;

TX: SMA/F,50Ω;

9

Operation Temperature

-25℃ ～ +70℃

10

Storage Temperature

-40℃ ～ +85℃

11

Humidity

≤95%

12

Dimension

196.5mm*134.5mm*85mm（L*W*H）

13

MTBF

≥100000h
