12.1 inch VGA HDMI Industrial Touch Monitor

Overview:

FA1210/C/T is a high brightness capacitive touch monitor. It has a native resolution of 1024 x 768 with support for signals up to 4K at 30 fps. With a brightness rating of 800 cd/m², a contrast ratio of 900:1, and viewing angles up to 170°. The monitor is equipped with HDMI, VGA, and 1/8" A/V inputs, an 1/8" headphone output, and two built-in speakers.

The display is designed to operate up from -30 to 80 degree C for safe use in industrial applications. It supports 12 to 24 VDC power supplies, allowing it to be used in a variety of settings.It equiped with 75mm VESA folding bracket, it can not only be retracted freely, but save space on the desktop,wall and roof mounts, etc.

Main Features:

Supports multiple video input interfaces: HDMI, VGA, CVBS, DVI(optional)Support 4K 30Hz HDMI inputHigh brightness 800cd/m2Capacitive touch screen is optionalIndividual adjustments of Brightness, Contrast, Brightness, Sharpness, Aspect and Color Temp, etc.Support Scan, Underscan, Zoom, Freeze functionsEquipped with 75mm VESA holesBuilt-in high level components to support 7 to 24V power supply voltageWide working temperature -30~80° C



Temperature Resistance

With special screen panel, it can work well in -30℃~80℃ environment, and storage in -30℃~85℃ temperature will not affect its performance.











It features 12.1" 4:3 LCD panel with 1024×768 resolution, 800 cd/m² high brightness, 900:1 contrast, 170° wide viewing angles, which has

high level of environment absolute rating so that the panel can operate in a higher or lower temperature.



Moreover, flexible applications would be applied to various environments, such as commercial public display, outdoor advertising, industrial

operation and so on.





Interfaces

Compatible with HDMI (support 4K 30Hz) and VGA signals. Also, the touch driver loaded by USB can realize the touch operation on the screen.



Wide Voltage Power

Built-in high level components to support 12 to 24V power supply voltage, allows to be used in more places.







Equiped with 75mm VESA folding bracket, it can not only be retracted freely, but save space on the desktop, wall and roof mounts, etc.





Parameters:



SPLAY	Panel	12.1"  IPS
	Physical Resolution	1024×768
	Touch Panel	capacitive
	Aspect Ratio	4:3
	Brightness	800 nits
	Contrast	900:1
	Viewing Angle	170°/170  °(H/V)
INPUT	HDMI 1.4b	1 (support 4K 30Hz)
	VGA	1
	Mini usb	1 (upgrade)
	USB	1 (for touch function)
	A/V	1
AUDIO	Speaker	2
	Ear Jack	1
POWER	Current	≤1.1A (12V)
	Input Voltage	DC 12-24V
	Power Consumption	≤13W
ENVIRONMENT	Operating Temperature	-30℃~80℃
	Storage Temperature	-30℃~85℃
DIMENSION	Dimension(LWD)	284.4mm × 224.1mm × 33.4mm
	Mounting Method	VESA 75mm
	Weight	1.27kg





Accessories:
