38 Series 515 High Elastic TPR Caster

38 Series 515 High Elastic TPR Caster

Wheel Diameter：125mm (5")

Wheel Width：38mm (1-1/2")

Wheel Type：High Elastic TPR / TPR (Hardness：65 Shore A / 85 Shore A)

Moving Loading：200 KG

Type：Rigid、Swivel Plate 、Plate with Brake

Brake Type：Total Brake or Side Brake

Plate Size：115 x 100mm (thk. ：6mm)

Bolt Hole Spacing：76~92mm x 66~76mm

Total Height：165mm

Bearing：Precision Bearing #6202 ZZ (Hole：15mm)

Features：

1. low coefficient of friction~ mobile，effective， and time-saving

2. sturdy and durable，much better than traditional black rubber wheel (which is made and mixed from waste rubber and unknown black materials).

3. satisfy the frequent moving needs， especially for the logistics carts.
