720P RS232 JPEG Camera with wide angle lens_Telecommunication & Broadcasting_Electronics & Electricity_Products

Top Selling

品牌：: LCF

Model: LCF-23IRCB

Origin: Made In China

Label: rs232 camera , jpeg camera , jpeg serial camera

Model No.: LCF-23IRCB

Application

General purpose embedded imaging and control.

Security system

Access Control system

Robot vision, object detection and recognition.

Industrial control system.

Automotive system.

Medical systems etc.

Features

1. Working by day and light(IR LED)

2. Low cost and low powered camera for embedded imaging applications.

3. On-board EEPROM provides a command-based interface to external host via RS232,RS485 and TTL serial link.

4. UART: up to 115200bps for transferring JPEG still pictures

5. Support fast continuous snapshotting

6. Built-in down sampling, clamping and windowing circuits for 1280X720,VGA, QVGA, 160x120 image resolutions.

7. Auto-Infrared, Auto-White Balance, Auto-Gain Control.

No.	Item	Description
1	Image sensor	CMOS
2	Pixels	1.0 mega pixels
3	Image Resolution	1280720,640480 320X240 160X120
4	Image Compression	JPEG
5	Focal Length	2.5mm 3.6mm 6.0mm
6	Angle of View	150°120° 90°
7	Minimum lumen	1 Lux
8	Night Vision lumen	5 Lux
9	Night Vision Image	Black-White Image
10	Night Vision Distance	3-10M
11	Serial Interface	RS232 TTL RS485
12	Baud Rate	9600-115200bps
13(1)	Connector	Customize for customer(any connector is available)
(2)	PIN Description	DC5V/24V TXD RXD GND
14	Length of Cable	Customize for customer(2m is default one)
15	White Balance	Automatic
16	Exposure	Automatic
17	Auto Gain Control	Automatic
18	Weight	0.3KG
19	Size	92Φ*66h(mm)
20	Working Current	IR Off: 50-80mA IR On: 250-350mA
21	Power Supply	5V
22	Working Temperature	-15°C~70°C
23	Datasheet/Protocol	LCF Protocol
24	PC Test Software	Support

Contacts

Company Name: Lianchao Future Technology Co.,Ltd.

Name:: Mr. Felix Rong

Telephone: 86-755-23116486

Address

Operational Address: Building 3,No.5,East of Wenwu, Red Star Village,Songgang Town,Baoan District,Shenzhen,China
