Dr. Schneider PC Benchtop Ionizing Air Blowr SL-001

The desktop ionizing blower produces an airflow that is rich in positive and negative ions. Directing the airflow on an object that has a static electricity charge will neutralize the charge.

The desktop ionizing blower is a portable ionized air blower. It uses a small fan to produce airflow. The volume of airflow is controlled by a variable speed control, which provides a wide range of airflow setting. The high voltage AC is applied to a circular arrangement of tungsten steel ion emitter points, which results in an intense alternating electric field at the tip of the emitter points. It is this electric field that creates alternating polarity ions in the airflow. To assure that the unit is working properly, the high voltage AC is monitored by an ionization indicator lamp.

 Features

Small, light weight and portableRapidly neutralizes static chargesVariable speed fan with wide range of air flowInherently balanced ion outputIonization indicator lampWith warm function.

ION OUTPUT (DISCHARGE TIME)

Away from lonizer	Left 300mm	Center line	Right 300mm
300mm		1.3sec
600mm	3.2sec	2.5sec	3.3sec
900mm	6.4sec	4.6sec	6.5sec

1.  Distance measured in mm, decay time measured in seconds.

2.  Test data available using ME 268A charges plate analyzer.

3. Test figures are subject to the variation in the atmospheric conditions.

4．Discharge times are in seconds from 1000 volts to 100 volts.
