Duct Air Quality Sensors

• With maintenance-free CO2 sensing element based on optical infrared absorption
measurement (NDIR1)
• and – depending on the type of sensor – VOC2) sensing element, based on a
heated tin dioxide semiconductor
• CO2 temperature and CO2 humidity-temperature multisensor
• No recalibrations required
• Operating voltage AC 24 V or DC 15…35 V
• Signal outputs DC 0...10 V

In air ducts of ventilation and air conditioning plant to enhance room comfort and to
optimize energy consumption by providing demand-controlled ventilation. The sensor
acquires:
• CO2 concentrations
• VOC concentrations as an indication of odors in the duct air, such as tobacco smoke,
body odor, or material fumes
• The relative humidity of the duct air
• The duct air temperature
The QPM21… can be used as a:
• Control sensor in the supply or extract air duct
• Transmitter for building automation and control systems and / or display units
Typical use:
• Acquisition of CO2 and VOC concentrations:
In party rooms, lounges, fair pavillions and exhibition halls, restaurants, canteens,
shopping malls, sports gymnasiums, sales rooms, and conference rooms
• Acquisition of CO2 concentrations:
In ventilation plant of rooms with varying occupancy levels where smoking is prohibited, such as museums, theatres, movie theatres, auditoriums, office spaces and
school rooms

• The QPM21… sensors are not suited for use as safety devices, such as gas or
smoke warning devices!
• The sensors must not be used outdoors!

Type reference	CO2 measuring range	VOC sensitivity	Temperature measuring range	Humidity measuring range	Measured value display
QPM2100	0…2000 ppm	---	---	---	no
QPM2102	0…2000 ppm	low (R1) Normal (R2) High(R3)	---	---	no
QPM2102D	0…2000 ppm	low (R1) Normal (R2) High(R3)	---	---	yes
QPM2160	0…2000 ppm	---	0...50 °C / −35...+35 °C	---	no
QPM2160D	0…2000 ppm	---	0...50 °C / −35...+35 °C	---	yes
QPM2162	0…2000 ppm	---	0...50 °C / −35...+35 °C	0---100%	no
QPM2162D	0…2000 ppm	---	0...50 °C / −35...+35 °C	0---100%	yes
