IR metal dome RS232 Serial Camera(0.3MP)

No.

Item

Description

1

Image sensor

CMOS

2

Pixels

0.3 mega pixels

3

Image Resolution

640*480 320X240 160X120

4

Image Compression

JPEG

5

Focal Length

2.5mm  3.6mm

6

Angle of View

120°  90°

7

Minimum lumen

1 Lux

8

Night Vision lumen

5 Lux

9

Night Vision Image

Black-White Image

10

Night Vision Distance

3-10M

11

Serial Interface

RS232 TTL RS485

13

Baud Rate

9600-115200bps

14(1)

Connector

Customize for customer(any connector is available)

(2)

 PIN Description

PIN 1: DC 5V

PIN 2: TXD

PIN 3: RXD

PIN 4: GND

15

Length of Cable

Customize for customer(2m is default one)

16

White Balance

Automatic

17

Exposure

Automatic

18

Auto Gain Control

Automatic

19

Weight

0.4KG

20

Size

92Φ*66h(mm)

21

Working Current

IR Off: 50-80mA

IR On: 250-320mA

22

Standby Current

30-80mA

23

Power Supply

5V

24

Working Temperature

-15°C~70°C

25

Datasheet/Protocol

LCF Protocol

26

PC Test Software

Support
