Description:
Lilliput 21.5 inch professional high brightness 1000nits monitor with FHD resolution,101% rec.709 color space. The video monitor come with center makers and safety makers , allowing to adjust the best angle of the cameras in real time to show the most important images in center of shot.It can applicate for live events conference presentation ,public view monitoring.etc…
Features:
- Model NO.: PVM210S(with SDI) / PVM210(without SDI)
- 21.5'', 16:9, 1920*1080, 1000nits high brightness
- Interfaces: HDMI( support 4K 30Hz) / VGA/ 3G-SDI/ AV inputs; 3G-SDI output
- Support HDR10&HLG
- metal housing, support destop
- Application: Public view/Education/ Concert/Live Stream/E-sport/Wedding,etc
Specification:
| Model | PVM210S | PVM210 | |
| DISPLAY | Panel | 21.5 ” LCD | 21.5 ” LCD |
| Physical Resolution | 1920*1080 | 1920*1080 | |
| Aspect Ratio | 16:9 | 16:9 | |
| Brightness | 1000 cd/m² | 1000 cd/m² | |
| Contrast | 1500：1 | 1500：1 | |
| Viewing Angle | 170°/170°(H/V) | 170°/170°(H/V) | |
| Color Space | 101% Rec.709 | 101% Rec.709 | |
| HDR Supported | HLG;ST2084 300/1000/10000 | HLG;ST2084 300/1000/10000 | |
| INPUT | SDI | 1 x 3G SDI | - |
| HDMI | 1 x HDMI 1.4b | 1 x HDMI 1.4b | |
| VGA | 1 | 1 | |
| AV | 1 | 1 | |
| OUTPUT | SDI | 1 x 3G-SDI | - |
| SUPPORTED FORMATS | SDI | 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60… | - |
| HDMI | 2160p 24/25/30, 1080p 24/25/30/50 /60, 1080i 50/60, 720p 50/60… | 2160p 24/25/30, 1080p 24/25/30/50 /60, 1080i 50/60, 720p 50/60… | |
| AUDIO IN/OUT | Speaker | 2 | 2 |
| SDI | 16ch 48kHz 24-bit | - | |
| HDMI | 8ch 24-bit | 8ch 24-bit | |
| Ear Jack | 3.5mm-2ch 48kHz 24-bit | 3.5mm-2ch 48kHz 24-bit | |
| POWER | Input Voltage | DC12-24V | DC12-24V |
| Power Consumption | ≤36W (15V) | ≤36W (15V) | |
| ENVIRONMENT | Operating Temperature | 0℃~50℃ | 0℃~50℃ |
| Storage Temperature | -20℃~60℃ | -20℃~60℃ | |
| Dimension | Dimension(LWD) | 524.8*313.3*19.8mm | 524.8*313.3*19.8mm |
| Weight | 4.8kg | 4.8kg |
| Model | PVM210S | PVM210 | |
| DISPLAY | Panel | 21.5 ” LCD | 21.5 ” LCD |
| Physical Resolution | 1920*1080 | 1920*1080 | |
| Aspect Ratio | 16:9 | 16:9 | |
| Brightness | 1000 cd/m² | 1000 cd/m² | |
| Contrast | 1500：1 | 1500：1 | |
| Viewing Angle | 170°/170°(H/V) | 170°/170°(H/V) | |
| Color Space | 101% Rec.709 | 101% Rec.709 | |
| HDR Supported | HLG;ST2084 300/1000/10000 | HLG;ST2084 300/1000/10000 | |
| INPUT | SDI | 1 x 3G SDI | - |
| HDMI | 1 x HDMI 1.4b | 1 x HDMI 1.4b | |
| VGA | 1 | 1 | |
| AV | 1 | 1 | |
| OUTPUT | SDI | 1 x 3G-SDI | - |
| SUPPORTED FORMATS | SDI | 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60… | - |
| HDMI | 2160p 24/25/30, 1080p 24/25/30/50 /60, 1080i 50/60, 720p 50/60… | 2160p 24/25/30, 1080p 24/25/30/50 /60, 1080i 50/60, 720p 50/60… | |
| AUDIO IN/OUT | Speaker | 2 | 2 |
| SDI | 16ch 48kHz 24-bit | - | |
| HDMI | 8ch 24-bit | 8ch 24-bit | |
| Ear Jack | 3.5mm-2ch 48kHz 24-bit | 3.5mm-2ch 48kHz 24-bit | |
| POWER | Input Voltage | DC12-24V | DC12-24V |
| Power Consumption | ≤36W (15V) | ≤36W (15V) | |
| ENVIRONMENT | Operating Temperature | 0℃~50℃ | 0℃~50℃ |
| Storage Temperature | -20℃~60℃ | -20℃~60℃ | |
| Dimension | Dimension(LWD) | 524.8*313.3*19.8mm | 524.8*313.3*19.8mm |
| Weight | 4.8kg | 4.8kg |
