JPEG Serial Camera with Metal case_Surveillance Equipment_Security & Protection_Products

Top Selling

品牌：: LCF

Model: LCF-23IRCM

Origin: Made In China

Label: jpeg serial camera , rs232 camera , serial jpeg camera

Model No.:LCF-23IRCM

Application

General purpose embedded imaging and control.

Security system

Access Control system

Robot vision, object detection and recognition.

Industrial control system.

Automotive system.

Medical systems etc.

Features

1. Working by day and light(IR LED)

2. Low cost and low powered camera for embedded imaging applications.

3. On-board EEPROM provides a command-based interface to external host via RS232,RS485 and TTL serial link.

4. UART: up to 115200bps for transferring JPEG still pictures

5. Support fast continuous snapshotting

6. Built-in down sampling, clamping and windowing circuits for VGA, QVGA, 160x120 image resolutions.

7. Auto-Infrared, Auto-White Balance, Auto-Gain Control.

No.	Item	Description
1	Image sensor	CMOS
2	Pixels	0.3 mega pixels
3	Image Resolution	640*480 320X240 160X120
4	Image Compression	JPEG
5	Focal Length	2.5mm 3.6mm 6mm optional
6	Angle of View	120° 90° 60° optional
7	Minimum lumen	1 Lux
8	Night Vision lumen	5 Lux
9	Night Vision Image	Black-White Image
10	Night Vision Distance	3-10M
11	Serial Interface	RS232 TTL RS485
12	Baud Rate	9600-115200bps
13(1)	Connector	Customize for customer(any connector is available)
(2)	PIN Description	PIN 1: DC 5/12V/24V PIN 2: TXD PIN 3: RXD PIN 4: GND
14	Length of Cable	Customize for customer(2m is default one)
15	White Balance	Automatic
16	Exposure	Automatic
17	Auto Gain Control	Automatic
18	Weight	0.4KG
19	Working Current	IR Off: 50-80mA IR On: 250-320mA
20	Power Supply	5V
21	Working Temperature	-15°C~70°C
22	Datasheet/Protocol	LCF Protocol
23	PC Test Software	Support
24	Material of Case	metal case
